Control Arm/BMW/5 (F10)/5 Gran Turismo (F07)/5 Touring (F11)/6 Coupe (F13)/6 Gran Coupe (F06)/7 (F01, F02, F03, F04)/i8 (I12)/i8 Roadster (I15)

CS-945

Designation Control Arm
Position FRONT UPPER LH/ RH
OE No. 2 450 817 / 31 12 2 450 817 / 31 12 6 775 967 / 31 12 6 779 871 / 31 12 6 779 908 / 31 12 6 854 613 / 31 12 6 854 614 / 31 12 6 857 516 / 6 775 967 / 6 779 871 / 6 779 908 / 6 854 613 / 6 854 614 / 6 857 516
Length 286 mm
Width 263 mm
Height 83 mm
Net Weight 1.2 kg
CTE No. DESIGNATION POSITION OE NO.
CBH09034 FRONT UPPER ARM INNER
31 10 6 864 374
31 10 6 868 530
31 10 6 881 320
31 10 6 883 115
31 10 6 883 116
31 12 6 775 981
6 775 981
6 864 374
6 868 530
6 881 320
6 883 115
6 883 116
CBH09035 FRONT UPPER ARM INNER
31 12 6 775 979
6 775 979
CBH09036 FRONT LOWER ARM INNER
31 12 6 775 980
31 12 6 791 455
6 775 980
6 791 455
CBH09037 FRONT LOWER ARM OUTER
31 10 6 784 569
31 12 6 784 569
6 784 569
CBH09060 REAR UPPER LH/RH
33 32 6 775 902
COS09009 FRONT,REAR
CRE09009 D= M14X1.5 , C= M18X1.5
32 10 6 784 716
32 10 6 784 719
32 10 6 784 792
6 784 716
6 784 719
6 784 792
CS-945 FRONT UPPER LH/ RH
2 450 817
31 12 2 450 817
31 12 6 775 967
31 12 6 779 871
31 12 6 779 908
31 12 6 854 613
31 12 6 854 614
31 12 6 857 516
6 775 967
6 779 871
6 779 908
6 854 613
6 854 614
6 857 516
CS-946L FRONT UPPER LH
31 12 6 775 971
6 775 971
CS-946R FRONT UPPER RH
31 12 6 775 972
6 775 972
CS-947L FRONT LOWER LH
2 450 813
31 12 2 450 813
31 12 6 794 203
6 794 203
CS-947L-6 FRONT LOWER LH
2 450 813
31 12 2 450 813
31 12 6 794 203
6 794 203
CS-947R FRONT LOWER RH
2 450 814
31 12 2 450 814
31 12 6 794 204
6 794 204
CS-947R-6 FRONT LOWER RH
2 450 814
31 12 2 450 814
31 12 6 794 204
6 794 204
CS-960 REAR UPPER LH/RH
33 32 6 775 902
6 775 902
CS-978 FRONT UPPER LH/ RH
CS-979 FRONT UPPER LH/ RH
CSL09027 FRONT AXLE LH/RH
31 35 6 777 319
6 777 319
CSR09010L FRONT AXLE LH
32 10 6 784 716
6 784 716
CSR09010R FRONT AXLE RH
32 10 6 784 719
6 784 719
CTE09013L FRONT AXLE LH (C= M14X1.5)
32 10 6 784 790
6 784 790
CTE09013R FRONT AXLE RH (C= M14X1.5)
32 10 6 784 796
6 784 796
Model (Year)
B7 (F01, F02)
Model (Year)
5 (F10)
5 Gran Turismo (F07)
5 Touring (F11)
6 Convertible (F12)
6 Coupe (F13)
6 Gran Coupe (F06)
7 (F01, F02, F03, F04)
i8 (I12)
i8 Roadster (I15)
Model (Year)
5 SERIES (F10, F18)
Model (Year)
GHOST I (RR4)
