COS17002
| Designation | Repair Kit |
| Position | FRONT |
| OE No. | |
| Length | 450 mm |
| Width | 350 mm |
| Height | 225 mm |
| Net Weight | 9.35 kg |
| CTE No. | DESIGNATION | POSITION | OE NO. | |
|---|---|---|---|---|
 |
CBH17004 | FRONT AXLE | 9173618 9443882 9465971 |
|
 |
CBH17008 | REAR AXLE INNER | 31277893 9169204 |
|
 |
CBH17009 | REAR AXLE INNER | 30645401 31277952 9157579 |
|
 |
CBH17010 | REAR AXLE OUTER | 9127363 |
|
 |
CBH17011 | FRONT LOWER ARM REAR | 30760590 31360784 8630604 9461626 |
|
 |
CBH17017 | REAR AXLE INNER | 9492181 |
|
 |
CBH17026 | FRONT LOWER ARM INNER | 271631 6800251 |
|
 |
CBH17028 | FRONT LOWER ARM INNER | 272227 272273 2722734 272274 2722742 272336 272337 2723385 2723393 277227 8628493 8628494 8628497 86284973 8628498 86284981 9140976 9140977 9186730 9186731 9492291 9492292 9492532 9492533 9492673 9492674 9492916 9492917 |
|
 |
CBH17029L | FRONT LOWER ARM LH REAR | 31200776 |
|
 |
CBH17029R | FRONT LOWER ARM RH REAR | 31200775 |
|
 |
CBH17030 | FRONT LOWER ARM INNER | 1507181 1507182 31200775 31200776 31262473 31262475 31277345 31277346 31277525 31277526 31317663 31317664 31317665 31317666 31340127 31340128 31429320 31429321 7G9N 3A052 BB 7G9N 3A053 BB LR007205 LR007206 |
|
 |
CBJ17006A | FRONT LOWER LH/ RH | 271591 2715910 3546524 |
|
 |
CBJ17010A | FRONT LOWER LH/ RH | 1377846 1377848 1385593 1385594 1403408 1403410 1419814 1419815 1426875 1426876 1435745 1435747 1458773 1460693 1466186 1466188 1469024 1469026 1507181 1507182 30671636 30671637 31200448 31200449 31200563 31200564 31200775 31200776 31212781 31212782 31277 |
|
 |
COS17002 | FRONT | ||
 |
CRE17008 | D= M14X2.0 , C= M14X1.5 | 31476353 3546266 35462662 |
|
 |
CRE17017 | D= M14X2.0 , C= M16X1.5 | 9191410 91914101 9191410SK1 |
|
 |
CS-1709L | FRONT LOWER LH | 271091 271628 271901 3516182 3546701 8628491 8628495 9492287 9492530 9492671 9492914 |
|
 |
CS-1709R | FRONT LOWER RH | 271629 271902 272092 3516183 3546702 8628492 8628496 9492288 9492531 9492672 9492915 |
|
 |
CS-1710L | FRONT LOWER LH | 272273 2722734 272336 2723385 8628493 8628497 86284973 9140976 9186730 9492291 9492532 9492673 9492916 |
|
 |
CS-1710R | FRONT LOWER RH | 272227 272274 2722742 272337 2723393 277227 8628494 8628498 86284981 9140977 9186731 9492292 9492533 9492674 9492917 |
|
 |
CS-1716L | FRONT LOWER LH | 31200776 |
|
 |
CS-1716R | FRONT LOWER RH | 31200775 |
|
 |
CSL03048 | REAR (A= 179MM) | 1377349 1377398 1377416 1425853 1502681 1783320 30736875 30736947 30736948 30760678 31429561 31451817 31476579 6G915C486XAA 6G915C486XAB 8V41-5C486-AA CV615C486AAB |
|
 |
CSL17005 | FRONT (A= 303MM) | 1387860 1387860-8 30647921 30647995 30714686 8626031 8628703 8628726 9140767 9492804 9492804-1 |
|
 |
CSL17006 | FRONT (A= 244.5MM) | 272991 6819253 9492837 |
|
 |
CSL17013 | REAR (A= 140MM) | 30647920 30714678 31201603 8634869 8672446 9169080 |
|
 |
CSL17015 | FRONT (A= 332MM) | 274303 274456 30647919 30714685 31201602 31212692 8634736 8672445 9200603 |
|
 |
CSL17017 | REAR (A= 140MM) | 30647920 30714678 31201603 8634869 8672446 9169080 |
|
 |
CTE17003L | FRONT AXLE LH (C= M14X2.0) | 22715985 271598 2715985 3546267 |
|
 |
CTE17003R | FRONT AXLE RH (C= M14X2.0) | 271599 2715993 3546268 |
| Model (Year) |
|---|
|
S60 I (384) V70 I (875, 876) V70 II (285) |
